STANDARD EQUIPMENT
FAGOR DRO X,Y,Z
Sensitive handwheel
2 reducer sleeve (from MT4 to MT3 and MT2)
Drill chuck capacity 3 – 16mm
MT4 collet chuck set
Mechanical vice 160mm with rotating base
Work light
CE Certified
| Max. drilling capacity | mm | 50 |
| Max. drilling capacity in steel | mm | 35 |
| Max. drilling capacity in cast iron | mm | 40 |
| Max. reaming capacity | mm | 50 |
| Max. milling capacity | mm | 25 |
| Headstock turning | mm | ±45º |
| X axis travel | mm | 380 |
| Y axis travel | mm | 200 |
| Table surface | mm | 800×240 |
| Transmission | Gears | |
| Feeds range | 8 | |
| No. and range of spindle feeds | mm/min | (LOW) |
| 115-290-360-875 | ||
| (HIGH) | ||
| 230-580-720-1750 | ||
| Spindle taper | CM/MT | 4 |
| Spindle stroke | mm | 120 |
| Spindle diameter | mm | ø90 |
| Distance spindle to table min – max | mm | 0 – 400 |
| Column type | Prismatic | |
| Table T-slot size | mm | 5-T14 |
| Main motor power | Kw/Cv | 0.85/1.5 |
| Electrical voltage | V/Hz | 230-400V/50 Hz |
| Dimensions (L x W x H) | mm | 1200x1200x1700 |
| Net weight | Kg | 500 |
