STANDARD EQUIPMENT
Digital RPM display, Headstock swivel, Rotary table 50º 600×400 mm, Cubic table X600 Y4200 Z300 mm, Depth setting
Drill ejector, Cooling System, Led Work light, Tool box, CE-Certified
| Max. drilling capacity steel 60 | Kg | 40 |
| Max. tapping diameter steel 60 | Kg | 30 |
| Maximum spindle stroke | mm | 200 |
| Distance between column axis and T-slot in the middle of the work table | mm | 640 |
| Max. distance from spindle to work table surface | mm | 760 |
| Maximum ram travel | mm | 590 |
| Ram vertical travel | mm | 400 |
| Head rotation | º | +/-90 |
| Spindle taper | CM/ MT | 4 |
| Transmission | Gear | |
| Clutch | Electromag. | |
| Number of speeds | (variable) | |
| Range of speeds | r.p.m | 50-316 / 3162000 |
| Number of feeds | 6 | |
| Range feeds | r.p.m | 0.08-0.50 |
| Table surface | mm | 1200×505 |
| Column diameter | mm | 220 |
| Electrical voltage | 230-400V/50 Hz | |
| Motor power | Kw/Cv | 2,2/3 |
| Dimensions (LxWxH) | mm | 1720x1200x2250 |
| Net weight | Kg | 2740 |
