STANDARD EQUIPMENT
2 PCS 4-jaw chuck 520mm, MD310T11B Inverter 11Kw, Taper turning attachment effective, working length 500mm, Working lamp, Coolant system, Dead center MT5, Foundation bolt, Oil gun
| Height of points | mm | 405 |
| Distance between points | mm | 1500 – 3000 |
| Diameter over bedplate | mm | 800 |
| Diameter over carriage | mm | 520 |
| Bed width | mm | 550 |
| Main spindle bore | mm | 206 |
| Type and No. of speeds | Mechanical | 4 |
| Spindle speeds range | rpm | 20-500 |
| Longitudinal feeds | mm/r | 0,07-1,3 |
| Transverse feeds | mm/r | 0,02-0,45 |
| Metric threads | mm | (24)1-14mm |
| Inch threads | tpi | (40)2-28 |
| Leadscrew pitches | “ | 1/2″ |
| Cross slide travel | mm | 420 |
| Top rest travel | mm | 200 |
| Maximum tool dimensions | mm | 32×32 |
| Tailstock quill diameter | mm | 100 |
| Tailstock quill travel | mm | 250 |
| Tailstock Morse taper | CM/MT | 5 |
| Main motor power | Kw/CV | 11/15 |
| Electrical voltage | V/Hz | 230-400V/50 Hz |
| Motor pump power | Kw/CV | 0,125/0,167 |
| Dimensions (L x W x H) | mm | 3700x1550x1550 |
| 5200x1550x1550 | ||
| Net weight | Kg | 4.300 -5500 |
