STANDARD EQUIPMENT
Fagor 8055 control
Steady rest open type
3 jaws chuck
Peripheral wheel dresser
Wedge
Coolant system
CE Certificate
| Distance between center | mm | 3000 |
| External grinding diameter | mm | 25-500 |
| Internal grianding diameter | mm | 30-100 |
| Max. Length external grinding | mm | 3000 |
| Max. Wieght workpiece | Kg | 500 |
| Center height | mm | 250 |
| Wheel diameter | mm | Ø600x75x305 |
| Peripheral wheel speed | m/s | 35 |
| Speed wheel spindle | r/min | 1100 |
| Table speed | m/min | 0.1-4 |
| External wheel size | mm | 3100 |
| Headstock spindle rotation speed | CM/MT | 4 |
| Headstock and tailstock center | Kw/CV | 30/40 |
| Electrical voltage | V/Hz | 230-400V/50 Hz |
| Dimensions (L x W x H) | mm | 7605x1810x2000 |
| Weight | Kg | 8600 |
