POSSIBLE CONFIGURATIONS
Adaptable configuration of the different grinding wheel dressing systems with diamond or plunge roller, with diamond roller on composite slide, or combined. Axial movement of the grinding spindle is possible. There is also the possibility of plunging. Simple and intuitive man-machine interface developed on Siemens Sinumerik Operate systems. Extension of feeding-load systems, in motion and size according to the different needs of users. Ability to record data locally and / or decentralized. Possibility of interfacing feeding systems, loading and / or unloading systems from the factory and completing them with other machines in the production process. to the network of remote maintenance and / or remote diagnosis systems.
| TECHNISCHE DATEN | |
|---|---|
| SCHLEIFEN-FÄHIGKEIT | |
| Durchmesser des Werkstücks | minimal 3 mm maximal 80 mm |
| Länge des Werkstücks – Einstech | 400 mm |
| SCHLEIFSCHEIBE | |
| Maximale Breite | 400 mm |
| Externer Durchmesser | 610 mm |
| Durchmesser-Bohrung | 304,8 mm |
| Umfangsgeschwindigkeit | 50 (63) m/s |
| Antriebsmotor | 51 kW |
| REGELSCHEIBE | |
| Maximale Breite | 400 mm |
| Externer Durchmesser | 350 mm |
| Durchmesser-Bohrung | 203,2 mm |
| Minimale Geschwindigkeit | 5 U/min |
| Maximale Geschwindigkeit | 200 U/min |
| Abricht-Geschwindigkeit | 400 U/min |
| Drehmoment Gleichstrommotor | 20 Nm |
| NETTOGEWICHT DER MASCHINE | 11000 kg |
| ABMESSUNGEN DER MASCHINE | 3900 x 1600 mm |
