STANDARD EQUIPMENT 510/600/800 SZ
Full table Enclosure
FAGOR DRO X Y Z
Fine pole electromagnetic chuck
Coolant system with magnetic separator
suction unit
Diamond Support
Automatic X-Y-Z Axis
Y axis ballscrew
Grinding wheel dresser
Work light
Automatic X Y Z Axis
Grinding wheel with flange
Balancing stand/arbor
CE Certificate
| Working Surface of Table | mm | 600×300 |
| Max.Table Travel | mm | 660 |
| Max.Cross Travel | mm | 340 |
| Distance Between Table Surface and Spindle | mm | 520 |
| Max.Table Load | Kgs | 420 |
| T-Solt (Number x Width) | mm | 1×14 |
| Table Speed | m/min | 5~25 |
| Electromagnetic chuck dimenssions (L x W) | mm/mm | 600х300 |
| Automatic Crossfeed of Saddle | mm | 0.01~12 |
| Automatic Crossfeed Rate | mm/min | 10~800 |
| Power Cross Feed | mm/min | 1500 |
| Grinding Wheel Dimensions | mm | 355x40x127 |
| Spindle Speed 50HZ | 1450 | |
| Spindle Speed 60HZ | 1740 | |
| Automatic Down Feed Rate | mm | 0.002/0.004/0.00 |
| 6/0.012/0.02/0.03 | ||
| /0.04/0.05 | ||
| Power Head Increment | mm/min | 400 |
| Spindle Motor | Kw/Cv | 38111 |
| Coolant system | Kw/Cv | 0.09/0.12 |
| Hydraulic motor | Kw/Cv | 37377 |
| Transverse motor | Kw/Cv | 0.4/0.5 |
| Floor Space | mm | 2600×2500 |
| Electrical voltage | V/Hz | 230-400V/50 Hz |
| Packing Dimensions (LxWxH) | mm | 2150x1940x2195 |
| Net Weight | Kgs | 1960 |
| Gross Weight | Kgs | 2250 |
